Metal Ministry Inc. is one of the known manufacturer of Stainless Steel 409 Forged Products that are being sourced from the raw materials and as per the national and international standard. Alloy 409 is a general purpose, chromium, titanium stabilized, ferritic stainless steel whose primary application is automotive exhaust systems. It contains 11% chromium which is the minimum amount for the formation of the passive surface film which gives stainless steels their corrosion resistance.
It is commonly used in applications where appearance is a secondary quality to mechanical properties and corrosion resistance. Alloy 409 resists corrosion strongly compared to carbon steel and is used as an alternative to carbon steel in mildly challenging environments where its high resistance to corrosion and high temperature oxidation gives an advantage.
| Stainless Steel 409 Forged Fittings | Stainless Steel 409 Forged Round Bars |
| Stainless Steel 409 Forged Hex Bars | Stainless Steel AISI 409 Forged Elbow |
| AISI 409 Stainless Steel Forged Flanges | Stainless Steel 409 Forged Stubends |
| Stainless Steel UNS S40900 Forged Caps | Stainless Steel UNS S40900 Forged Fasteners |
| Stainless Steel AISI 409 Forged Billets | Stainless Steel AISI 409 Forged Reducer |
| Stainless Steel UNS S40900 Forged Tee | Stainless Steel 409 Forged Pipes |
| Stainless Steel 409 Forged Tubes | Stainless Steel UNS S40900 Forged Circles |
| Stainless Steel 409 Forged Square Bars | Stainless Steel 409 Forged Valves |
| Stainless Steel AISI 409 Forged Flat Bars | Stainless Steel UNS S40900 Forged Shafts |
| Stainless Steel 409 Forged Rings | Stainless Steel 409 Forged Discs |
| Stainless Steel AISI 409 Forged Blocks | Stainless Steel UNS S40900 Forged Extrusions |
| Stainless Steel 409 Forged Custom Shapes | Stainless Steel AISI 409 Forged Machined Parts |
We likewise offer these Stainless Steel 409 (UNS S40900) Forged Products in tweaked sizes and thicknesses according to particular requests by our regarded customers at advertise driving costs.
| Grade | C | Mn | Si | P | S | Cr | Ni | Ti |
|---|---|---|---|---|---|---|---|---|
| 409 | max:0.08 | max:1.0 | max:1.0 | max:0.045 | max: 0.045 | min: 10.5 max: 11.75 | max: 0.5 | min: 0.48 max: 0.75 |
| Grade | Tensile Strength MPa (min) | Yield Strength 0.2% MPa(min) | Elongation % | Hardness (Brinell) MAX | Hardness (Rockwell B) MAX |
|---|---|---|---|---|---|
| 409 | 380 | 207 | 20 | 207 | 95 |
| Density lbm/in3 |
Thermal Conductivity (BTU/h ft. °F) |
Electrical Resistivity (in x 10-6) |
Modulus of Elasticity (psi x 106 |
Coefficient of Thermal Expansion (in/in)/ °F x 10-6 |
Specific Heat (BTU/lb/ °F) |
Melting Range (°F) |
|---|---|---|---|---|---|---|
| at 68°F: 0.280 | 9.4 at 212°F | 28.3 at 68°F | 29 | 5.84 at 32 – 212°F | 0.114 at 68°F to 212°F | 2500 to 2590 |
| 12.4 at 932 °F | 39.4 at 752°F | 6.60 at 32 – 1000°F | ||||
| 49.6 at 1652 °F | 6.86 at 32 – 1500°F |
Metal Ministry Inc. exports Stainless Steel 409 Forged Products to Mumbai, Thane, Navi Mumbai, Pune, Pimpri-Chinchwad, Vadodara, Kolkata, Gurgaon, Ahmedabad, New Delhi, Bengaluru, Chennai, Surat, Bhopal, Ulsan, Faridabad, Houston, Dubai, Seoul, Hyderabad, Singapore, Abu Dhabi, Tehran, Calgary, Noida, Riyadh, London, Coimbatore, Jakarta, Istanbul, Bangkok, Kuwait City, Sharjah, Muscat, Edmonton, Busan, Mexico City, Doha, Jeddah, Aberdeen, Cairo, Geoje-si, Perth, Santiago, Chandigarh, Indore, Kuala Lumpur, Rio de Janeiro, Dammam, Melbourne, Madrid, La Victoria, Bogota, Lahore, Los Angeles, Algiers, Chiyoda, Ankara, Ho Chi Minh City, Toronto, Hong Kong, Rajkot, Brisbane, Petaling Jaya, Ernakulam, Secunderabad, Gimhae-si, Al Jubail, Port-of-Spain, Thiruvananthapuram, Milan, Atyrau, Lagos, Hanoi, Howrah, Sydney, Ahvaz, Karachi, New York, Caracas, Vung Tau, Al Khobar, Manama, Montreal, Granada, Courbevoie, Visakhapatnam, Ludhiana, Moscow, Dallas, Haryana, Colombo
Metal Ministry Inc. exports Stainless Steel 409 Forged Products to India, Saudi Arabia, Bangladesh, United States, United Arab Emirates, Canada, Angola, Argentina, Austria, Azerbaijan, Pakistan, Peru, Chile, Spain, France, United Kingdom, Indonesia, Israel, Iran, Kuwait, Mexico, Malaysia, Nigeria, Serbia, Singapore, Taiwan, Chile, Venezuela, Ecuador, Netherlands, Brazil, Colombia, Ghana, Iran, Denmark, Poland, Australia, Afghanistan, Bahrain, Costa Rica, Egypt, Iraq, Jordan, South Korea, Kazakhstan, Sri Lanka, Lithuania, Norway, Oman, Philippines, Poland, Qatar, Russia, Vietnam, South Africa, Nigeria, Mexico, Turkey, Hungary, Algeria, Belarus, Belgium, Bhutan, Bolivia, Bulgaria, Croatia, Czech Republic, Estonia, Finland, Greece, Italy, Japan, Libya, Romania, Thailand, Trinidad & Tobago,Tunisia, Ukraine, Yemen, Hong Kong, Gabon, China, Portugal, Switzerland, New Zealand, Sweden, Slovakia, Kenya, Lebanon, Morocco, Mongolia
All our Stainless Steel 409 Forged Products can be available with Black & Bright Surface as well as Finished surfaces. All these products are available with Relevent Mill Test Certificates, Heat treatment along with UT testing or NDT testing as required by the clients.
