Metal Ministry Inc. is one of the leading manufacturer of Hastelloy S Forging as per the quality standards. It retains strength and ductility after aging at temperature of 425 to 870°C[800 to 1600°F]. Hastelloy S is mainly developed for applications involving severely cyclical heating conditions where components must be capable of retaining strength, ductility, and metallurgical integrity after long time exposure and are extensively used as seal rings in gas turbine engines where its low thermal expansion coefficients is also important.
They have high creep and oxidation resistance. They are capable of functioning at very high temperatures and severe mechanical stress, and also where high surface stability is required.
| Hastelloy S Forged Fittings | Hastelloy S Forged Round Bars |
| Hastelloy S Forged Hex Bars | Hastelloy AISI S Forged Elbow |
| AISI S Hastelloy Forged Flanges | Hastelloy S Forged Stubends |
| Hastelloy UNS N06635 Forged Caps | Hastelloy UNS N06635 Forged Fasteners |
| Hastelloy AISI S Forged Billets | Hastelloy AISI S Forged Reducer |
| Hastelloy UNS N06635 Forged Tee | Hastelloy S Forged Pipes |
| Hastelloy S Forged Tubes | Hastelloy UNS N06635 Forged Circles |
| Hastelloy S Forged Square Bars | Hastelloy S Forged Valves |
| Hastelloy AISI S Forged Flat Bars | Hastelloy UNS N06635 Forged Shafts |
| Hastelloy S Forged Rings | Hastelloy S Forged Discs |
| Hastelloy AISI S Forged Blocks | Hastelloy UNS N06635 Forged Extrusions |
| Hastelloy S Forged Custom Shapes | Hastelloy AISI S Forged Machined Parts |
Also known as UNS N06635, our Hastelloy S Forgings are accessible to our valuable customers in different range of diameters, wall thicknesses and sizes in customized form and also at quite affordable rates.
| Elements | Content (%) |
|---|---|
| Nickel, Ni | 67 |
| Chromium, Cr | 14.5 – 17 |
| Molybdenum, Mo | 14 – 16.5 |
| Iron, Fe | 3 |
| Cobalt, Co | 2 |
| Tungsten, W | 1 |
| Copper, Cu | 0.35 |
| Manganese, Mn | 0.30 – 1.0 |
| Silicon, Si | 0.20 – 0.75 |
| Aluminum, Al | 0.10 – 0.50 |
| Carbon, C | 0.020 |
| Phosphorous, P | 0.020 |
| Boron, B | 0.015 |
| Sulfur, S | 0.015 |
| Lanthanum, La | 0.010 – 0.10 |
| Properties | Metric | Imperial |
|---|---|---|
| Tensile strength (@ 1093°C/1999°F, thickness 1.10-1.60 mm/0.0433-0.0630 in.) | 110 MPa | 16000 psi |
| Yield strength (@ 1093°C/1999°F, thickness 1.10-1.60 mm/0.0433-0.0630 in., 0.2% offset) | 52 MPa | 7540 psi |
| Elastic modulus | 212 GPa | 30700 ksi |
| Elongation at break (@ 982°C/1800°F, thickness 1.10-1.60 mm/0.0433-0.0630 in., in 50.8 mm) | 46% | 46% |
| Charpy Impact (V Notch; solution heat-treated, not aged) | 190 J | 140 ft-lb |
| Properties | Metric | Imperial |
|---|---|---|
| Density | 8.75 g/cm³ | 0.316 lb/in³ |
| Melting point | 1360°C | 2480°F |
Metal Ministry Inc. exports Hastelloy S Forged Products to Mumbai, Thane, Navi Mumbai, Pune, Pimpri-Chinchwad, Vadodara, Kolkata, Gurgaon, Ahmedabad, New Delhi, Bengaluru, Chennai, Surat, Bhopal, Ulsan, Faridabad, Houston, Dubai, Seoul, Hyderabad, Singapore, Abu Dhabi, Tehran, Calgary, Noida, Riyadh, London, Coimbatore, Jakarta, Istanbul, Bangkok, Kuwait City, Sharjah, Muscat, Edmonton, Busan, Mexico City, Doha, Jeddah, Aberdeen, Cairo, Geoje-si, Perth, Santiago, Chandigarh, Indore, Kuala Lumpur, Rio de Janeiro, Dammam, Melbourne, Madrid, La Victoria, Bogota, Lahore, Los Angeles, Algiers, Chiyoda, Ankara, Ho Chi Minh City, Toronto, Hong Kong, Rajkot, Brisbane, Petaling Jaya, Ernakulam, Secunderabad, Gimhae-si, Al Jubail, Port-of-Spain, Thiruvananthapuram, Milan, Atyrau, Lagos, Hanoi, Howrah, Sydney, Ahvaz, Karachi, New York, Caracas, Vung Tau, Al Khobar, Manama, Montreal, Granada, Courbevoie, Visakhapatnam, Ludhiana, Moscow, Dallas, Haryana, Colombo
Metal Ministry Inc. exports Hastelloy S Forged Products to India, Saudi Arabia, Bangladesh, United States, United Arab Emirates, Canada, Angola, Argentina, Austria, Azerbaijan, Pakistan, Peru, Chile, Spain, France, United Kingdom, Indonesia, Israel, Iran, Kuwait, Mexico, Malaysia, Nigeria, Serbia, Singapore, Taiwan, Chile, Venezuela, Ecuador, Netherlands, Brazil, Colombia, Ghana, Iran, Denmark, Poland, Australia, Afghanistan, Bahrain, Costa Rica, Egypt, Iraq, Jordan, South Korea, Kazakhstan, Sri Lanka, Lithuania, Norway, Oman, Philippines, Poland, Qatar, Russia, Vietnam, South Africa, Nigeria, Mexico, Turkey, Hungary, Algeria, Belarus, Belgium, Bhutan, Bolivia, Bulgaria, Croatia, Czech Republic, Estonia, Finland, Greece, Italy, Japan, Libya, Romania, Thailand, Trinidad & Tobago,Tunisia, Ukraine, Yemen, Hong Kong, Gabon, China, Portugal, Switzerland, New Zealand, Sweden, Slovakia, Kenya, Lebanon, Morocco, Mongolia
All our Hastelloy S Forged Products can be available with Black & Bright Surface as well as Finished surfaces. All these products are available with Relevent Mill Test Certificates, Heat treatment along with UT testing or NDT testing as required by the clients.
